Design & Manufacturing Technology Division
Planning &Machining Section

This facility is equipped with various general-purpose lathes, CNC Turning centers, Milling machines, CNC Milling & Boring Machines, Vertical Turret Lathes, Jig Boring Machine; CNC EDM wire cut machines and Grinding Machines. These machines are capable of machining precision components with high dimensional tolerance and surface finish.

Machine shop floor of DMTD
Machine shop floor of DMTD

Precision Machines of Planning &Machining Section

5 – Axes machining centre
5 – Axes machining centre
DMF-180/7, M/s. DMG, Germany make
Working range:
1800 x 700 x 700 mm
Spindle RPM-14000 with SK-40 taper
Positional accuracies < 4μ m
Repeatability < 3.5 μm
Spindle run-out <2 μm




Hollow spindle lathe model
Hollow spindle lathe model: WSU 40 x 1.5m
CNC control: Fanuc oi-TD
Maximum turning diameter :700 mm
Swing over bed: 1000 mm
Admit between centre: 1500 mm
Number of tool stations:12
RPM range : 21-1200 rpm
Positional accuracies:X-10μm,Z-12μm
Repeatability: 6μm (X &Z axis)
Spindle run out: 5 μm




Jig Boring Machine
Jig Boring Machine
MP 52 DR, M/s. SIP, Houser, Switzerland make
Working range:
900 x 600 x 600 mm
Spindle diameter -110 mm with ISO 40 taper
Positional accuracies < 4μm
Spindle run-out <1 μm




UP-65 Turn Mill Centre
UP-65 Turn Mill Centre
4 Axes turn mill centre
M/s. Spinner, Germany make
Working Range: Diameter 210 x 640 mm length
8-Live tools
Positional accuracies < 1 μm
Run-out < 1 μm
CNC control - Siemens 840 D




4 Axes - CNC Horizontal Boring  Machine
4 Axes - CNC Horizontal Boring Machine
AZ-11 M/s. HMT, India
Working Range:
X-1600mm
Y-1170mm
Z-600mm
W-1300mm
Position accuracies < 30μm
Spindle diameter 110mm having ISO-50 taper
Spindle Run out < 20 μm
CNC system- Siemens 840 D
Capacity- 04 Tones




CNC Vertical Turret Lathe
CNC Vertical Turret Lathe
M/s. Kirloskar make
Dynacut 150
Table diameter 1500
Maximum job height 1300mm
CNC system FANUC make -OTC
Positional accuracies <30 μm
Run out < 20 μm
Capacity -15 Tones




LAL 2B CNC Lathe
LAL 2B CNC Lathe
M/s. LMW, make,
Working range diameter
250 x 500mm
Position accuracies < 5 μm
Spindle run out < 5 μm
8 stations hydraulically operated turret
CNC system - FANUC -OT




PILATUS 25 T CNC Lathe
PILATUS 25 T CNC Lathe
M/s. LMW, make
Working range diameter
250 x 500mm
Position accuracies < 15 μm
Spindle run out < 10 μm
8 stations hydraulically operated turret
CNC- FANUC –OiMate TC




SMART TURNCNC Lathe
SMART TURNCNC Lathe
M/s. L M W, make.
Working range
Diameter 165 x 480mm
Position accuracies < 15μm
Spindle run out < 10 μm
8 stations hydraulically operated turret
CNC- FANUC-OiMate TC




LX20T L7 CNC Lathe
LX20T L7 CNC Lathe
M/s. L M W, make.
Chuck diameter 210 x 600mm turning length
Position accuracies < 7μm
Spindle run out < 5 μm
8 stations hydraulically
operated turret
CNC- Siemens-828D Basic




4 Axes - CNC Horizontal  Machining Center
4 Axes - CNC Horizontal Machining Center
CMH-500
AZ-11 M/s. AMS, India
Working Range:
X-800mm
Y-550mm
Z-550mm
Position accuracies < 5μm
Spindle having BT-50 taper
Spindle Run out < 10 μm
CNC system- Siemens 828 D
Capacity- 500kG




3 - Axes CNC Milling Machine
3 - Axes CNC Milling Machine
M/s. BFW make. BMV 40
Working range
500 x 400 x 450mm
Spindle Taper ISO 40
Spindle run out <2 μm
Positional accuracies <5 μm
CNC system - FANUC- OMI




4 axes CNC Universal Milling
Machine
4 axes CNC Universal Milling Machine
M/s. LMW, make.
model UME 600
Working range
600 x 500 x 450mm
Spindle Taper ISO 40
Spindle run out <2 μm
Positional accuracies <5 μm
CNC system - Hidenhen -TNC-426
C axis - CNC rotary table 450m




4 axes horizontal machining center
4 axes horizontal machining center
H1250i
M/s. BFW, Bangalore India
Working Range:
X-2000mm
Y-1500mm
Z-1400mm
Position accuracies < 15μm
Spindle having BT-50 taper
Spindle Run out < 10 μm
CNC system- Siemens 840 D
Capacity- 6000kG




3axes Machining Center
3axes Machining Center
BMV 51TC24
Vayu M/s BFW, India
Working range
825 x 510 x 510mm
Spindle Taper BT40
Spindle run out <5 μm
Positional accuracies <7 μm
CNC system – Siemens 828D




Surface Grinding Machine
Surface Grinding Machine
M/s. HMT make model - SFW-1
Working range
250mm x 1000mmx 400mm
Spindle run out <2 μm




CNC EDM Flush Type Wire Cut Machine
CNC EDM Flush Type Wire Cut Machine
M/s. Electronica, make, model- Ultra cut -F-2
X stroke-600mm
Y stroke - 400mm
Z stroke - 300mm
Accuracies - ± 10 μm




CNC EDM  Submersed Type Wire Cut Machine
CNC EDM Submersed Type Wire Cut Machine
M/s. Electronica, make, model- Ultra cut -S-2
X stroke -600mm
Y stroke - 400mm
Z stroke - 400mm
Accuracies - ±10 μm


Team Members:

Sh.Sanjay Chouksey, Head, Planning & Machining Section
The team consists of 40 members including Engineers and skilled technicians.
